## Black Holes* as a possible source of Universal Dark Energy

Previously I have written about the possibility of primordial black holes as the explanation for dark matter, and on the observational constraints around such a possibility.

But maybe it is dark energy, not dark matter, that black holes explain. More precisely,  it would be dark energy stars (or gravatars, or GEODEs) that are observationally similar to black holes.

Dark energy

Dark energy is named thusly because it has negative pressure. There is something known as an equation of state that relates pressure to energy density. For normal matter, or for dark matter, the coefficient of the relationship, w, is zero or slightly positive, and for radiation it is 1/3.

If it is non-zero and positive then the fluid component loses energy as the universe expands, and for radiation, this means there is a cosmological redshift. The redshift is in proportion to the universe’s linear scale factor, which can be written as the inverse of the cosmological redshift plus one, by normalizing it to the present-day scale. The cosmological redshift is a measure of the epoch as well, currently z = 0, and the higher the redshift the farther we look back into the past, into the earlier years of the universe. Light emitted at frequency ν is shifted to lower frequency (longer wavelength) ν’ = ν / (1 + z).

Since 1998, we have known that we live in a universe dominated by dark energy (and its associated dark pressure, or negative pressure). The associated dark pressure outweighs dark energy by a factor of 3 because it appears 3 times, once for each spatial component in Einstein’s stress-energy tensor equations of general relativity.

Thus dark energy contributes a negative gravity, or expansion acceleration, and we observe that our universe has been accelerating in its expansion for the past 4 or 5 billion years, since dark energy now provides over 2/3 of the universal energy balance. Dark matter and ordinary matter together amount to just less than 1/3 of the average rest-mass energy density.

If w is less than -1/3 for some pervasive cosmological component, then you have dark energy behavior for that component, and in our universe today over the past several billion years, measurements show w = -1 or very close to it. This is the cosmological constant case where dark energy’s negative pressure has the same magnitude but the opposite sign of the positive dark energy density. More precisely, the dark pressure is the negative of the energy density times the speed of light squared.

Non-singular black holes

There has been consideration for decades of other types of black holes that would not have a singularity at the center. In standard solutions of general relativity black holes have a central singular point or flat zone, depending on whether their angular momentum is zero or positive.

For example a collapsing neutron star overwhelms all pressure support from neutron degeneracy pressure once its mass exceeds the TOV limit at about 2.7 solar masses (depending on angular momentum), and forms a black hole that is often presumed to collapse to a singularity.

But when considering quantum gravity, and quantum physics generally, then there should be some very exotic behavior at the center, we just don’t know what. Vacuum energy is one possibility.

For decades various proposals have been made for alternatives to a singularity, but the problem has been observationally intractable. A Soviet cosmologist Gliner, who was born just 100 years ago in Kyiv, and who only passed away in 2021, proposed the basis for dark energy stars and a dark energy driven cosmology framework in 1965 (in English translation, 1966).

E. Gliner, early 1970s in St. Petersburg, courtesy Gliner family

He defended his Ph.D. thesis in general relativity including dark energy as a component of the stress-energy tensor in 1972. Gliner emigrated to the US in 1980.

The essential idea is that the equation of state for compressed matter changes to that of a material (or “stuff”) with a fully negative pressure, w = -1 and thus that black hole collapse would naturally result in dark energy cores, creating dark energy stars or gravatars rather than traditional black holes. The cores could be surrounded with an intermediate transition zone and a skin or shell of normal matter (Beltracchi and Gondolo 2019). The dark energy cores would have negative pressure.

Standard black hole solution is incomplete

Normally black hole physics is attacked with Kerr (non-zero angular momentum) or Schwarzschild (zero angular momentum) solutions. But these are incomplete, in that they assume empty surroundings. There is no matching of the solution to the overall background which is a cosmological solution. The universe tracks an isotropic and homogeneous (on the largest scales) Lambda-cold dark matter (ΛCDM) solution of the equations of general relativity. Since dark energy now dominates, it is approaching a de Sitter exponential runaway, whereas traditional black hole solutions with singularities are quite the opposite, known as anti-de Sitter.

We have no general solution for black hole equations including the backdrop of an expanding universe. The local Kerr solution for rotating black holes that is widely used ignores the far field. Really one should match the two solution regimes, but there has been no analytical solution that does that; black hole computations are very difficult in general, even ignoring the far field.

In 2019, Croker and Weiner of the University of Hawaii found a way to match a model of dark energy cores to the standard ΛCDM cosmology, and demonstrate that for w = -1 that dark energy stars (black holes with dark energy cores) would have masses that grow in proportion to the cube of the universe’s linear scale factora, starting immediately from their initial formation at high redshifts. In effect they are forced to grow their masses and expand (with their radius proportional to mass as for a black hole) by all of the other dark energy stars in the universe acting in a collective fashion. They call this effect, cosmological coupling of the dark energy star gravity to the long-range and long-term cosmological gravitational field.

This can be considered a blueshift for mass, as distinguished from the energy or frequency redshift we see with radiation in the cosmos.

Their approach potentially addresses several problems: (1) an excess of larger galaxies and their supermassive black holes seen very early on in the recent James Webb Space Telescope data, (2) more intermediate mass black holes than expected, as confirmed from gravitational wave observations of black hole mergers, (see Coker, Zevin et al. 2021 for a possible explanation via cosmological coupling), and (3) possibly a natural explanation for all or a substantial portion of the dark energy in the universe, which has been assumed to be highly diffuse rather than composed primarily of a very large number of point sources.

Inside dark energy stars, the dark energy density would be many, many orders of magnitude higher than it is in the universe at large. But as we will see below, it might be enough to explain all of the dark energy budget of the ΛCDM cosmology.

M87* supermassive black hole (or dark energy star) imaged in polarized radio waves by the Event Horizon Telescope collaboration; signals are combined from a global collection of radio telescopes via aperture synthesis techniques. European Southern Observatory, licensed under a Creative Commons Attribution 4.0 International License

A revolutionary proposal

Here’s where it gets weird. A number of researchers have investigated the coupling of a black hole’s interior to an external expanding universe. In this case there is no singularity but instead a vacuum energy solution interior to the (growing) compact stellar remnant.

And one of the most favored possibilities is that the coupling causes the mass for all black holes to grow in proportion to the universe’s characteristic linear size a cubed, just as if it were a cosmological constant form of dark energy. This type of “stuff” retains equal energy density throughout all of space even as the space expands, as a result of its negative pressure with equation of state parameter w = -1.

Just this February a very interesting pair of papers has been published in The Astrophysical Journal (the most prestigious American journal for such work) by a team of astronomers from 9 countries (US, UK, Canada, Japan, Netherlands, Germany, Denmark, Portugal, and Cyprus), led by the University of Hawaii team mentioned above.

They have used observations of a large number of supermassive black holes and their companion galaxies out to redshift 2.5 (when the universe was less than 3 billion years of age) to argue that there is observable cosmologicalcouplingbetween the cosmological gravitational field at large and the SMBH masses, where they suppose those masses are dominated by dark energy cores.

Their argument is that the black hole* (or *dark energy star) masses have grown much faster than could be explained by the usual mechanism of accretion of nearby matter and mergers.

In Figure 1 from their second paper of the pair (Farrah, Croker, et al. 2023), they present their measurements of the strength of cosmological coupling for five different galaxy surveys (three sets of galaxies but two sets were surveyed at two frequencies each). They observed strong increases in the measured SMBH masses from redshifts close to z =1 and extending above z = 2. They derive a coupling strength parameter k that measures the power law index of how fast the black hole masses grow with redshift.

Their reformulation of the black hole model to include the far field yields cosmological coupling of the dark energy cores. The mass of the dark energy core, coupled to the overall cosmological solution, results in a mass increase M ~ a^k , a power law of index k, depending on the equation of state for the dark energy. Here a is the cosmological linear scale factor of the universal expansion and is also equal to 1/(1+z) where z is the redshift at which a galaxy and its SMBH are observed. (The scale factor a is normalized to 1 presently, such that z = 0 now and is positive in the past).

And they are claiming that their sample of several hundred galaxies and supermassive black holes indicates k = 3, on average, more or less. So between z = 1 and z = 0, over the past 8 billion years, they interpret their observations as an 8-fold growth in black hole masses. And they say this is consistent with M growing by a^3 as the universe’s linear scale has doubled (a was 1/2 at z = 1). This implies they are measuring a different class of black holes than we normally think of, those don’t increase in mass other than by accretion and mergers. Normal black holes would yield k > 0 but not by much, based on expected accretion and mergers. The k = 0 case they state is excluded by their observations with over 99.9% confidence.

The set of upper graphs in Figure 1 is for the various surveys, and the large lower graph combines all of the surveys as a single data set. They find a near-Gaussian distribution, and k is centered near 3, with an uncertainty close to 1. There is a 2/3 chance that the value lies between 2.33 and 3.85, based on their total sample of over 400 active galaxy nuclei.

And they also suggest this effect would be for all dark energy dominated “black holes”, including stellar class and intermediate BHs, not just SMBHs. So they claim fast evolution in all dark energy star masses, in proportion to the volume growth of the expanding universe, and consistent with dark energy cores having an equation of state just like the observed cosmological constant.

Now it gets really interesting.

We already know that the dark energy density of the universe, unlike the ever-thinning mater and radiation density, is more or less constant in absolute terms. That is the cosmological constant, due to vacuumenergy, interpretation of dark energy for which the pressure is negative and causes acceleration of the universe’s expansion. Each additional volume of the growth has its own associated vacuum energy (around 4 proton masses’ worth of rest energy per cubic meter). This is the universe’s biggest free lunch since its original creation.

The authors focus on dark energy starts created during the earliest bursts of star formation. These are the so-called Pop III stars, never observed because all or mostly all have reached end of life long ago. When galaxy and star formation starts as early as about 200 million years after the Big Bang, there is only hydrogen and helium for atomic matter. Heavier elements must be made in those first Pop III stars. As a result of their composition, the first stars with zero ‘metallacity’ have higher stellar masses; high mass stars are the ones that evolve most rapidly and they quickly end up as white dwarfs, or more to the point here, black holes or neutron stars in supernovae events. Or, they end their lives as dark energy stars.

The number of these compact post supernova remnant stars will decrease in density in inverse proportion to the increasing volume of the expanding universe. But the masses of all those that are dark energy stars would increase as the cube of the scale factor, in proportion to the increasing volume.

And the net effect would be just right to create a cosmological constant form of dark energy as the total contribution of billions upon billions of dark energy stars. And dark energy would be growing as a background field from very early on. Regular matter and dark matter thin out with time, but this cohort would have roughly constant energy density once most of the first early rounds of star formation completed, perhaps by redshift z = 8, well within the first billion years. Consequently, dark energy cores, collectively, would dominate the universe within the last 4 or 5 billion years or so, as the ordinary and dark matter density fell off. And now its dominance keeps growing with time.

But is there enough dark energy in cores?

But is it enough? How much dark energy is captured in these dark energy stars, and can it explain the dominant 69% of the universe’s energy balance that is inferred from observations of distant supernovae, and from other methods?

The dark energy cores are presumably formed from the infall and extreme compression of ordinary matter, from baryons captured into the progenitors of these black hole like stars and being compressed to such a high degree that they are converted into a rather uniform dark energy fluid. And that dark energy fluid has the unusual property of negative pressure that prevents further compression to a singularity.

It is possible they could consume some dark matter, but ordinary matter clumps much more easily since it can radiate away energy via radiation, which dark matter does not do. Any dark matter consumption would only build their case here, but we know the overall dark matter ratio of 5:1 versus ordinary matter has not changed much since the cosmic microwave background emission after the first 380,000 years.

We know from cosmic microwave background measurements and other observations, that the ordinary matter or baryon budget of the universe is just about 4.9%, we’ll call it 5% in round numbers. The rest is 69% dark energy, and 26% dark matter.

So the question is, how much of the 5% must be locked up in dark energy stars to explain the 69% dark energy dominance that we currently see?

Remember that with dark energy stars the mass grows as the volume of the universe grows, that is in proportion to (1 + z)3. Now dark energy stars will be formed at different cosmological redshifts, but let’s just ask what fraction of baryons would we need to convert, assuming all are formed at the same epoch. This will give us a rough feel for the range of when and of how much.

Table 1 looks at some possibilities. It asks what fraction of baryons need to collapse into dark energy cores, and we see that the range is from only about 0.2% to 1% of baryons are required. Those baryons are just 5% of the mass-energy of the universe, and only 1% or less of those are needed, because the mass expansion factors range from about 1000 to about 10,000 — 3 to 4 orders of magnitude, depending on when the dark energy stars form.

Table 1. The first column has the redshift (epoch) of dark energy star formation. In actuality it will happen over a broad range of redshifts, but the earliest stars and galaxies seem to have formed from around 200 to 500 million years after the Big Bang started. The second column has the mass expansion factor (1+z)3; the DE star’s gravitational mass grows by that factor from the formation z until now. The third column is the age of the universe at DE star formation. The fourth column tells us what fraction of all baryons need to be incorporated into dark energy cores in those stars (they could be somewhat more massive than that). The fifth column is the lower bound on their current mass if they never experience a merger or accretion of other matter. All in all it looks as if less than 1% of baryons convert to dark energy cores.

The fifth column shows the current mass of a minimal 3 solar mass dark energy star at present, noting that 3 solar masses is the lightest known black hole. There may be lighter dark energy stars, but not very much lighter than that, perhaps a little less than 2 solar masses. And the number density should be highest at the low end according to everything we know about star formation.

Now to some degree these are underestimates for the final mass, as shown in the fifth column, since there will be mergers and accretion of other matter into these stars, and of the two effects, the mergers are more important, but they support the general argument. If a dark energy star merges with a neutron star, or other type of black hole, the dark energy core gains in relative terms. So all of this is a plausibility argument that says if the formation is of dark energy stars of a few solar masses in the epoch from 200 to 500 million years after the Big Bang, that less than 1% of all baryons are needed. And it says that the final masses are well into the intermediate range of thousands or tens of thousands of solar masses, and yet they can hide out in galaxies or between galaxies with hundreds of billions of solar masses, only contributing a few percent to the total mass.

Dark energy star cosmology

Dark energy star cosmology needs to agree with the known set of cosmological observations. It has to provide all or a significant fraction of the total dark energy budget in order to be useful. It appears from simple arguments that it can meet the budget by conversion of a small percentage of the baryons in the universe to dark energy stars.

It should exhibit an equation of state w = -1 or nearly so, and it appears to do that. It should not contribute too much mass to upset our galaxy mass estimates. It does that and it does not appear to explain dark matter in any direct way.

Dark energy stars collectively could potentially fill that role. In the model described above it is their collective effects that are being modeled as a dark energy background field that in turn drives dark energy star cores to higher masses over time. Dark energy (as a global field) feeds on itself (the dark energy cores)!

There are some differences with the normal ΛCDM cosmology assumption of a highly uniform dark energy background, not one composed of a very large number of point sources. In particular the ΛCDM cosmology has the dark energy background there from the very beginning, but it is not significant until,the universe has expanded sufficiently.

With the dark energy star case it has to be built up, one dark energy core at a time. So the dark energy effects do not begin until redshifts less than say z = 20 to 30 and most of it may be built up by z = 8 to 10, within the first billion years.

In the dark energy star case we will have accretion of nearby matter including stars, and mergers with neutron stars, other dark energy stars, and other black hole types.

A merger with a neutron star or non dark energy star only increases the mass in dark energy cores; it is positive evolution in the aggregate dark energy core component. A merger of two dark energy stars will lose some of the collective mass in conversion to gravitational radiation, and is a negative contribution toward the overall dark energy budget.

One way to distinguish between the two cosmological models is to push our measurement of the strength of dark energy as far back as we can and look for variations. Another is to identify as many individual intermediate scale black holes / dark energy stars as we can from gravitational wave surveys and from detailed studies of globular clusters and dwarf galaxies.

Dark matter’s ratio to ordinary matter at the time of the cosmic microwave background emission is measured to be 5:1 and currently in galaxies and their rotation curves and in clusters of galaxies in their intracluster medium it is also seen to be around 5:1 on average. Since the dark energy cores in the Croker et al. proposal are created hundreds of millions of years after the cosmic microwave background era, then these dark energy stars can not be a major contribution to dark matter per se.

The pair of papers just published by the team doesn’t really discuss dark matter implications. But a previous paper by Croker, Runburg and Farrah (2020) explored the interaction between the dark energy bulk behavior of the global population of dark energy stars with cold dark matter and found little or no affect.

Their process converts a rather small percentage of baryons (or even some dark matter particles) into dark energy and its negative pressure. Such material couples differently to the gravitational field than dark matter, which like ordinary matter is approximately dust-like with an equation of state parameter w = 0.

In the 2020 paper they find that GEODEs or dark energy stars can be spread out even more than dark matter that dominates galaxy halos, or the intracluster medium in rich clusters of galaxies.

This concept of cosmological coupling is one of the most interesting areas of observational and theoretical cosmology in this century. If this work by Croker and collaborators is confirmed the team will be winning prizes in astrophysics and cosmology, since it could be a real breakthrough in both our understanding of the nature of dark energy and our understanding of black hole physics.

In any case, Dark Energy Star already has its own song.

Glossary

Black Hole: A dense collection of matter that collapses inside a small radius, and in theory, to a singularity, and which has sufficiently strong gravity that nothing, not even light, is able to escape. Black holes are characterized by three numbers: mass, angular momentum, and charge.

Cosmological constant: Einstein added this term, Λ, on the left hand side of the equations of general relativity, in a search for a static universe solution. It corresponds to an equation of state parameter w = -1. If the term is moved to the right hand side it becomes a dark energy source term in the stress-energy tensor.

Cosmological coupling: The coupling of local properties to the overall cosmological model. For example, photons redshift to lower energies with the expansion of the universe. It is argued that dark energy stellar cores would collectively couple to the overall Friedmann cosmology that matches the bulk parameters of the universe. In this case it would be a ‘blueshift’ style increase in mass in proportion to the growing volume of the universe, or perhaps more slowly.

Dark Energy: Usually attributed to energy of the vacuum, dark energy has a negative pressure in proportion to its energy density. It was confirmed by Nobel prize winning teams that dark energy is the dominant component of the universe’s mass-energy balance, some 69% of the critical value, and is driving an accelerated expansion with an equation of state w = -1 to within small errors.

Dark Energy Star: A highly compact object that should look like a black hole externally but has no singularity at its core. Instead it has a core of dark energy. If one integrates over all dark energy stars, it may add up to a portion or all of the universe’s dark energy budget. It should have a crust of ‘normal’ matter with anisotropic stress at the boundary with the core, or an intermediate transition zone with varying equation of state between the crust and the core.

Dark Matter: An unknown substance thought to reside in galactic halos, with 5 times as much matter density on average as ordinary matter. Dark matter does not interact electromagnetically and is typically considered to be particulate in nature, although primordial mini black holes have been suggested as one possible explanation.

Equation of state: The relationship between pressure and energy density, P = w * ρ * c^2 where P is pressure and can be negative, and ρ the energy density is positive. If w < -1/3 there is dark pressure, if w = -1 it is the simplest cosmological constant form. Dark matter or a collection of stars or galaxies can be modeled as w ~ 0.

GEODEs: GEneric Objects of Dark Energy, dark energy stars. Formation is thought to occur from Pop III stars, the first stellar generation, at epochs 30 > z > 8.

Gravastar: A stellar model that has a dark energy core and a very thin outer shell. With normal matter added there is anisotropic stress at the boundary to maintain pressure continuity from the core to the shell.

Non-singular black holes: A black hole like object with no singularity.

Primordial black holes: Black holes that may have formed in the very early universe, within the first second. Primordial dark energy stars in large numbers would be problematic, because they would grow in mass by (1 + z)^3 where z >> 1000.

Vacuum energy: The irreducible energy of the vacuum state. The vacuum state is not empty, it is pervaded by fields and virtual particles that pop in and out of existence on very short time scales.

References

https://scitechdaily.com/cosmological-coupling-new-evidence-points-to-black-holes-as-source-of-dark-energy/ – Popular article about the research from University of Hawaii lead authors and collaborators

https://www.phys.hawaii.edu/~kcroker/ – Kevin Croker’s web site at University of Hawaii

Beltracchi, P. and Gondolo, P. 2019, https://arxiv.org/abs/1810.12400 “Formation of Dark Energy Stars”

Croker, K.S. and Weiner J.L. 2019, https://dor.org/10.3847/1538-4357/ab32da “Implications of Symmetry and Pressure in Friedmann Cosmology. I. Formalism”

Croker, K.S., Nishimura, K.A., and Farrah D., 2020 https://arxiv.org/pdf/1904.03781.pdf, “Implications of Symmetry and Pressure in Friedmann Cosmology. II. Stellar Remnant Black Hole Mass Function”

Croker, K.S., Runburg, J., and Farrah D., 2020 https://doi.org/10.3847/1538-4357/abad2f “Implications of Symmetry and Pressure in Friedmann Cosmology. III. Point Sources of Dark Energy that tend toward Uniformity”

Croker, K.S., Zevin, M.J., Farrah, D., Nishimura, K.A., and Tarle, G. 2021, “Cosmologically coupled compact objects: a single parameter model for LIGO-Virgo mass and redshift distributions” https://arxiv.org/pdf/2109.08146.pdf

Farrah, D., Croker, K.S. et al. 2023 February, https://iopscience.iop.org/article/10.3847/2041-8213/acb704/pdfObservational Evidence for Cosmological Coupling of Black Holes and its Implications for an Astrophysical Source of Dark Energy” (appeared in Ap.J. Letters 20 February, 2023)

Farrah, D., Petty S., Croker K.S. et al. 2023 February, https://doi.org/10.3847/1538-4357/acac2e “A Preferential Growth Channel for Supermassive Black Holes in Elliptical Galaxies at z <~ 2”

Ghezzi, C.R. 2011, https://arxiv.org/pdf/0908.0779.pdf “Anisotropic dark energy stars”

Gliner, E.B. 1965, Algebraic Properties of the Energy-momentum Tensor and Vacuum-like States of Matter. ZhTF 49, 542–548. English transl.: Sov. Phys. JETP 1966, 22, 378.

Harikane, Y., Ouchi, M., et al. arXiv:2208.01612v3, “A Comprehensive Study on Galaxies at z ~ 9 – 16 Found in the Early JWST Data: UV Luminosity Functions and Cosmic Star-Formation History at the Pre-Reionization Epoch”

Perrenod, S.C. 2017, “Dark Energy and the Cosmological Constant” https://darkmatterdarkenergy.com/2017/07/13/dark-energy-and-the-comological-constant/

Whalen, D.J., Even, W. et al.2013, doi:10.1088/004-637X/778/1/17, “Supermassive Population III Supernovae and the Birth of the first Quasars”

Yakovlev, D. and Kaminker, A. 2023, https://arxiv.org/pdf/2301.13150.pdf “Nearly Forgotten Cosmological Concept of E.B. Gliner”

## Does Dark Energy Vary with Time?

Einstein introduced the concept of dark energy 100 years ago.

The Concordance Lambda-Cold Dark Matter cosmology appears to fit observations of the cosmic microwave background and other cosmological observations including surveys of large-scale galaxy grouping exceedingly well.

In this model, Lambda is shorthand for the dark energy in the universe. It was introduced as the greek letter Λ into the equations of general relativity, by Albert Einstein, as an unvarying cosmological constant.

Measurements of Λ indicate that dark energy accounts for about 70% of the total energy content of the universe. The remainder is found in dark matter and ordinary matter, and about 5/6 of that is in the form of dark matter.

Alternative models of gravity, with extra gravity in very low acceleration environments, may replace apparent dark matter with this extra gravity, perhaps due to interaction between dark energy and ordinary matter.

The key point about dark energy is that while it has a positive energy, it rather strangely has a negative pressure. In the tensor equations of general relativity the pressure terms act as a negative gravity, driving an accelerated expansion of the universe.

In fact our universe is headed toward a state of doubling in scale in each dimension every 11 or 12 billion years. In the next trillion years we are looking at 80 or 90 such repeated doublings.

That assumes that dark energy is constant per volume over time, with a value equivalent to two proton – antiproton pair annihilations per cubic meter (4 GeV / m³).

But is it?

The Dark Energy Survey results seem to say so. This experiment looked at 26 million galaxies for the clustering patterns, and also gravitational lensing (Einstein taught us that mass bends light paths).

They determined the parameter w for dark energy and found it to be consistent with -1.0 as expected for the cosmological constant model of unvarying dark energy. See this blog for details:

https://darkmatterdarkenergy.com/2017/08/10/dark-energy-survey-first-results-canonical-cosmology-supported/

The pressure – energy density relation is:

$P = w \cdot \rho \cdot c^2$

The parameter w elucidates the relation between the energy density given by ρ and the pressure P. This is called the equation of state. Matter and radiation have w >= 0. In order to have dark energy with a negative pressure dominating, then w should be < -1/3. And w = -1 gives us the cosmological constant form.

Image credit: www.scholarpedia.org

Cosmologists seek to determine w, and whether it varies over time scales of billions of years.

The Concordance model is not very well tested at high redshifts with z > 1 (corresponding to epochs of the universe less than half the current age) other than with the cosmic microwave background data. Recently two Italian researchers, Risaliti and Lusso have examined datasets of high-redshift quasars to investigate whether the Concordance model fits.

Typically supernovae are employed for the redshift-distance relation, and cosmological models are tested against the observed relationship, known as the Hubble diagram. The authors use X-ray and ultraviolet fluxes of quasars to extend the diagram to high redshifts (greater distances, earlier epochs), and calibrate observed quasar luminosities with the supernovae data sets.

Their analysis drew from a sample of 1600 quasars with redshifts up to 5 and including a new sample of 30 high redshift z ~ 3 quasars, observed with the European XMM-Newton satellite.

They claim a 4 standard deviation variance for z > 2, a reasonably high significance.

Models with a varying w include quintessence models, with time-varying scalar fields. If w decreases below -1, it is known as phantom energy. Their results are suggestive of a value of w < -1, corresponding to a dark or phantom energy increasing with time.

For convenience cosmologists introduce a second parameter for possible evolution in w, writing as:

w = w0 + wa*(1-a)   ,where a, the scale factor equals 1/(1+z) and a = 1 for present day.

The best fit results for their analysis are with w0 = -1.4 and wa ~ 1, but these results have large errors, as shown in Figure 4 above, from their paper. Their results are within the red (2 standard deviation, or σ) and orange (3σ) contours. The outer 3σ contours almost touch the cosmological constant point that has w0 = -1 and wa = 0.

These are intriguing results that require further investigation. They are antithetical to quintessence models, and apparently in tension with a simple cosmological constant.

The researchers plan on further analysis in future work by including Baryon Acoustic Oscillation (large scale galaxy clustering) measurements at z > 2.

References

https://darkmatterdarkenergy.com/2017/08/10/dark-energy-survey-first-results-canonical-cosmology-supported/ – Results from Dark Energy Survey of galaxies

Risaliti, G. and Lusso, E. 2018 Cosmological constraints from the Hubble diagram of quasars at high redshifts https://arxiv.org/abs/1811.02590

## Dark Energy Survey First Results: Canonical Cosmology Supported

The Dark Energy Survey (DES) first year results, and a series of papers, were released on August 4, 2017. This is a massive international collaboration with over 60 institutions represented and 200 authors on the paper summarizing initial results. Over 5 years the Dark Energy Survey team plans to survey some 300 million galaxies.

The instrument is the 570-megapixel Dark Energy Camera installed on the Cerro Tololo Inter-American Observatory 4-meter Blanco Telescope.

Image: DECam imager with CCDs (blue) in place. Credit: darkenergysurvey.org

Over 26 million source galaxy measurements from far, far away are included in these initial results. Typical distances are several billion light-years, up to 9 billion light-years. Also included is a sample of 650,000 luminous red galaxies, lenses for the gravitational lensing, and typically these are foreground elliptical galaxies. These are at redshifts < 0.9 corresponding to up to 7 billion light-years.

They use 3 main methods to make cosmological measurements with the sample:

1. The correlations of galaxy positions (galaxy-galaxy clustering)

2. The gravitational lensing of the large sample of background galaxies by the smaller foreground population (cosmic shear)

3. The gravitational lensing of the luminous red galaxies (galaxy-galaxy lensing)

Combining these three methods provides greater interpretive power, and is very effective in eliminating nuisance parameters and systematic errors. The signals being teased out from the large samples are at only the one to ten parts in a thousand level.

They determine 7 cosmological parameters including the overall mass density (including dark matter), the baryon mass density, the neutrino mass density, the Hubble constant, and the equation of state parameter for dark energy. They also determine the spectral index and characteristic amplitude of density fluctuations.

Their results indicate Ωm of 0.28 to a few percent, indicating that the universe is 28% dark matter and 72% dark energy. They find a dark energy equation of state w = – 0.80 but with error bars such that the result is consistent with either a cosmological constant interpretation of w = -1 or a somewhat softer equation of state.

They compare the DES results with those from the Planck satellite for the cosmic microwave background and find they are statistically significant with each other and with the Λ-Cold Dark MatterΛ model (Λ, or Lambda, stands for the cosmological constant). They also compare to other galaxy correlation measurements known as BAO for Baryon Acoustic Oscillations (very large scale galaxy structure reflecting the characteristic scale of sound waves in the pre-cosmic microwave background plasma) and to Type 1a supernovae data.

This broad agreement with Planck results is a significant finding since the cosmic microwave background is at very early times, redshift z = 1100 and their galaxy sample is at more recent times, after the first five billion years had elapsed, with z < 1.4 and more typically when the universe was roughly ten billion years old.

Upon combining with Planck, BAO, and the supernovae data the best fit is Ωm of 0.30 with an error of less than 0.01, the most precise determination to date. Of this, about 0.25 is ascribed to dark matter and 0.05 to ordinary matter (baryons). And the implied dark energy fraction is 0.70.

Furthermore, the combined result for the equation of state parameter is precisely w = -1.00 with only one percent uncertainty.

The figure below is Figure 9 from the DES paper. The figure indicates, in the leftmost column the measures and error bars for the amplitude of primordial density fluctuations, in the center column the fraction of mass-energy density in matter, and in the right column the equation of state parameter w.

The DES year one results for all 3 methods are shown in the first row. The Planck plus BAO plus supernovae combined results are shown in the last row. And the middle row, the fifth row, shows all of the experiments combined, statistically. Note the values of 0.3 and – 1.0 for Ωm and w, respectively, and the extremely small error bars associated with these.

This represents continued strong support for the canonical Λ-Cold Dark Matter cosmology, with unvarying dark energy described by a cosmological constant.

They did not evaluate modifications to general relativity such as Emergent Gravity or MOND with respect to their data, but suggest they will evaluate such a possibility in the future.

References

https://arxiv.org/abs/1708.01530, “Dark Energy Survey Year 1 Results: Cosmological Constraints from Galaxy Clustering and Weak Lensing”, 2017, T. Abbott et al.

https://en.wikipedia.org/wiki/Weak_gravitational_lensing, Wikipedia article on weak gravitational lensing discusses galaxy-galaxy lensing and cosmic shear

## Dark Energy and the Cosmological Constant

I am seeing a lot of confusion around dark energy and the cosmological constant. What are they? Is gravity always attractive? Or is there such a thing as negative gravity or anti-gravity?

First, what is gravity? Einstein taught us that it is the curvature of space. Or as famous relativist John Wheeler wrote “Matter tells space how to curve, and curved space tells matter how to move”.

Dark Energy has been recognized with the Nobel Prize for Physics, so its reality is accepted. There were two teams racing against one another and they found the same result in 1998: the expansion of the universe is accelerating!

Normally one would have thought it would be slowing down due to the matter within; both ordinary and dark matter would work to slow the expansion. But this is not observed for distant galaxies. One looks at a certain type of supernova that always has a certain mass and thus the same absolute luminosity. So the apparent brightness can be used to determine the luminosity distance. This is compared with the redshift that provides the velocity of recession or velocity-determined distance in accordance with Hubble’s law.

A comparison of the two types of distance measures, particularly for large distances, shows the unexpected acceleration. The most natural explanation is a dark energy component equal to twice the matter component, and that matter component would include any dark matter. Now do not confuse dark energy with dark matter. The latter contributes to gravity in the normal way in proportion to its mass. Like ordinary matter it appears to be non-relativistic and without pressure.

Einstein presaged dark energy when he added the cosmological constant term to his equations of general relativity in 1917. He was trying to build a static universe. It turns out that such a model is unstable, and he later called his insertion of the cosmological constant a blunder. A glorious blunder it was, as we learned eight decades later!

Here is the equation:

$G_{ab}+\Lambda g_{ab} = {8\pi G \over c^{4}}T_{ab}$

The cosmological constant is represented by the Λ term, and interestingly it is usually written on the left hand side with the metric terms, not on the right hand side with the stress-energy (and pressure and mass) tensor T.

If we move it to the right hand side and express as an energy density, the term looks like this:

$\rho = {\Lambda \over8\pi G }$

with $\rho$ as the vacuum energy density or dark energy, and appearing on the right it also takes a negative sign. So this is a suggestion as to why it is repulsive.

The type of dark energy observed in our current universe can be fit with the simple cosmological constant model and it is found to be positive. So if you move $\Lambda$ to the other side of the equation, it enters negatively.

Now let us look at dark energy more generally. It satisfies an equation of state defined by the relationship of pressure to density, with P as pressure and ρ denoting density:

$P = w \cdot \rho \cdot c^2$

Matter, whether ordinary or dark, is to first order pressureless for our purposes, quantified by its rest mass, and thus takes w = 0. Radiation it turns out has w = 1/3. The dark energy has a negative w, which is why you have heard the phrase ‘negative pressure’. The simplest case is w = -1, which the cosmological constant, a uniform energy density independent of location and age of the universe. Alternative models of dark energy known as quintessence can have a larger w, but it must be less than -1/3.

Credit: http://www.scholarpedia.org/article/Cosmological_constant

Why less than -1/3? Well the equations of general relativity as a set of nonlinear differential equations are usually notoriously difficult to solve, and do not admit of analytical solutions. But our universe appears to be highly homogeneous and isotropic, so one can use a simple FLRW spherical metric, and in this case one end up with the two Friedmann equations (simplified by setting c =1).

$\ddot a/a = - {4 \pi G \over 3} ({\rho + 3 p}) + {\Lambda \over 3 }$

This is for a (k = 0) flat on large scales universe as observed. Here $\ddot a$ is the acceleration (second time derivative) of the scale factor a. So if $\ddot a$ is positive, the expansion of the universe is speeding up.

The $\Lambda$ term can be rewritten using the dark energy density relation above. Now the equation needs to account for both matter (which is pressureless, whether it is ordinary or dark matter) and dark energy. Again the radiation term is negligible at present, by four orders of magnitude. So we end up with:

$\ddot a/a = - {4 \pi G \over 3} ({\rho_m + \rho_{de} + 3 p_{de}})$

Now the magic here was in the 3 before the p. The pressure gets 3 times the weighting in the stress-energy tensor T. Why, because energy density is just there as a scalar, but pressure must be accounted for in each of the 3 spatial dimensions. And since p for dark energy is negative and equal to the dark energy density (times the square of the speed of light), then

$\rho + 3 p$ is always negative for the dark energy terms, provided w < -1/3. That unusual behavior is why we call it ‘dark energy’.

Overall it is a battle between matter and dark energy density on the one side, and dark energy pressure (being negative and working oppositely to how we ordinarily think of gravity) on the other. The matter contribution gets weaker over time, since as the universe expands the matter becomes less dense by a relative factor of $(1=z)^3$, that is the matter was on average denser in the past by the cube of one plus the redshift for that era.

Dark energy eventually wins out, because it, unlike matter does not thin out with the expansion. Every cubic centimeter of space, including newly created space with the expansion has its own dark energy, generally attributed to the vacuum. Due to the quantum uncertainty (Heisenberg) principle, even the vacuum has fields and non zero energy.

Now the actual observations at present for our universe show, in units of the critical density that

$\rho_m \approx 1/3$

$\rho_{de} \approx 2/3$

and thus

$p_{de} \approx - 2$

And the sum of them all is around -1, just coincidentally. Since there is a minus sign in front of the whole thing, the acceleration of the universe is positive. This is all gravity, it is just that some terms take the opposite side. The idea that gravity can only be attractive is not correct.

If we go back in time, say to the epoch when matter still dominated with $\rho_m \approx 2/3$ and  $\rho_{de} \approx 1/3$, then the total including pressure would be 2/3 +1/3 – 1, or 0.

That would be the epoch when the universe changed from decelerating to accelerating, as dark energy came to dominate. With our present cosmological parameters, it corresponds to a redshift of $z \approx 0.6$, and almost 6 billion years ago.

Image: NASA/STScI, public domain

## No Dark Energy?

Dark Energy is the dominant constituent of the universe, accounting for 2/3 of the mass-energy balance at present.

At least that is the canonical concordance cosmology, known as the ΛCDM or Lambda – Cold Dark Matter model. Here Λ is the symbol for the cosmological constant, the simplest, and apparently correct (according to most cosmologists), model for dark energy.

Models of galaxy formation and clustering use N-body simulations run on supercomputers to model the growth of structure (galaxy groups and clusters) in the universe. The cosmological parameters in these models are varied and then the models are compared to observed galaxy catalogs at various redshifts, representing different ages of the universe.

It all works pretty well except that the models assume a fully homogeneous universe on the large scale. While the universe is quite homogeneous for scales above a billion light-years, there is a great deal of filamentary web-like structure at scales above clusters, including superclusters and voids, as you can easily see in this map of our galactic neighborhood.

##### Galaxies and clusters in our neighborhood. IPAC/Caltech, by Thomas Jarrett – “Large Scale Structure in the Local Universe: The 2MASS Galaxy Catalog”, Jarrett, T.H. 2004, PASA, 21, 396

Well why not take that structure into account when doing the modeling? It has long been known that more local inhomogeneities such as those seen here might influence the observational parameters such as the Hubble expansion rate. Thus even at the same epoch, the Hubble parameter could vary from location to location.

Now a team from Hungary and Hawaii have modeled exactly that, in a paper entitled “Concordance cosmology without dark energy” https://arxiv.org/pdf/1607.08797.pdf . They simulate structure growth while estimating the local values of expansion parameter in many regions as their model evolves.

Starting with a completely matter dominated (Einstein – de Sitter) cosmology they find that they can reasonably reproduce the average expansion history of the universe — the scale factor and the Hubble parameter — and do that somewhat better than the Planck -derived canonical cosmology.

Furthermore, they claim that they can explain the tension between the Type Ia supernovae value of the Hubble parameter (around 73 kilometers per second per Megaparsec) and that determined from the Planck satellite observations of the cosmic microwave background radiation (67 km/s/Mpc).

Future surveys of higher resolution should be able to distinguish between their model and ΛCDM, and they also acknowledge that their model needs more work to fully confirm consistency with the cosmic microwave background observations.

Meanwhile I’m not ready to give up on dark energy and the cosmological constant since supernova observations, cosmic microwave background observations and the large scale galactic distribution (labeled BAO in the figure below) collectively give a consistent result of about 70% dark energy and 30% matter. But their work is important, something that has been a nagging issue for quite a while and one looks forward to further developments.

Dark Energy and Matter content of Universe

## Galaxy Clusters Probe Dark Energy

Rich (large) clusters of galaxies are significant celestial X-ray sources. In fact, large clusters of galaxies typically contain around 10 times as much mass in the form of very hot gas as is contained in their constituent galaxies.

Moreover, the dark matter content of clusters is even greater than the gas content; typically it amounts to 80% to 90% of the cluster mass. In fact, the first detection of dark matter’s gravitational effects was made by Fritz Zwicky in the 1930s. His measurements indicated that the galaxies were moving around much faster than expected from the known galaxy masses within the cluster.

Image credit: X-ray: NASA/CXC/Univ. of Alabama/A. Morandi et al; Optical: SDSS, NASA/STScI (X-ray emission is shown in purple)

The dark matter’s gravitational field controls the evolution of a cluster. As a cluster forms via gravitational collapse, ordinary matter falling into the strong gravitational field interacts via frictional processes and shocks and thermalizes at a high temperature in the range of 10 to 100 million degrees (Kelvins). The gas is so hot, that it emits X-rays due to thermal bremsstrahlung.

Recently, Drs. Morandi and Sun at the University of Alabama have implemented a new test of dark energy using the observed X-ray emission profiles of clusters of galaxies. Since clusters are dominated by the infall of primordial gas (ordinary matter) into dark matter dominated gravitational wells, then X-ray emission profiles – especially in the outer regions of clusters – are expected to be similar, after correcting for temperature variations and the redshift distance. Their analysis also considers variation in gas fraction with redshift; this is found to be minimal.

Because of the self similar nature of the X-ray emission profiles, X-ray clusters of galaxies can serve as cosmological probes, a type of ‘standard candle’. In particular, they can be used to probe dark energy, and to look at the possibility of the variation of the strength of dark energy over multi-billion year cosmological time scales.

The reason this works is that cluster development and mass growth, and corresponding temperature increase due to stronger gravitational potential wells, are essentially a tradeoff of dark matter and dark energy. While dark matter causes a cluster to grow, dark energy inhibits further growth.

This varies with the redshift of a cluster, since dark energy is constant per unit volume as the universe expands, but dark matter was denser in the past in proportion to (1 + z)^3, where z is the cluster redshift. In the early universe, dark matter thus dominated, as it had a much higher density, but in the last several billion years, dark energy has come to dominate and impede further growth of clusters.

The table below shows the percentage of the mass-energy of the universe which is in the form of dark energy and in the form of matter (both dark and ordinary) at a given redshift, assuming constant dark energy per unit volume. This is based on the best estimate from Planck of 68% of the total mass-energy density due to dark energy at present (z = 0). Higher redshift means looking farther back in time. At z = 0.5, around 5 billion years ago, matter still dominated over dark energy, but by around z = 0.3 the two are about equal and since then (for smaller z) dark energy has dominated. It is only since after the Sun and Earth formed that the universe has entered the current dark energy dominated era.

Table: Total Matter & Dark Energy Percentages vs. z

 Redshift Dark Energy percent Matter percent 0 68 32 0.25 52 48 0.5 39 61 0.75 28 72 1.0 21 79 1.5 12 88

The authors analyzed data from a large sample consisting of 320 clusters of galaxies observed with the Chandra X-ray Observatory. The clusters ranged in redshifts from 0.056 up to 1.24 (almost 9 billion years ago), and all of the selected clusters had temperatures measured to be equal to or greater than 3 keV (above 35 million Kelvins). For such hot clusters, non-gravitational astrophysical effects, are expected to be small.

Their analysis evaluated the equation of state parameter, w, of dark energy. If dark energy adheres to the simplest model, that of the cosmological constant (Λ) found in the equations of general relativity, then w = -1 is expected.

The equation of state governs the relationship between pressure and energy density; dark energy is observed to have a negative pressure, for which w < 0, unlike for matter.

Their resulting value for the equation of state parameter is

w = -1.02 +/- 0.058,

equal to -1 within the statistical errors.

The results from combining three other experiments, namely

1. Planck satellite cosmic microwave background (CMB) measurements
2. WMAP satellite CMB polarization measurements
3. optical observations of Type 1a supernovae

yield a value

w = -1.09 +/- 0.19,

also consistent with a cosmological constant. And combining both the X-ray cluster results with the CMB and optical results yields a tight constraint of

w = -1.01 +/- 0.03.

Thus a simple cosmological constant explanation for dark energy appears to be a sufficient explanation to within a few percent accuracy.

The authors were also able to constrain the evolution in w and find, for a model with

w(z) = w(0) + wa * z / (1 + z), that the evolution parameter is zero within statistical errors:

wa = -0.12 +/- 0.4.

This is a powerful test of dark energy’s existence, equation of state, and evolution, using hundreds of X-ray clusters of galaxies. There is no evidence for evolution in dark energy with redshift back to around z = 1, and a simple cosmological constant model is supported by the data from this technique as well as from other methods.

References:

1. Morandi, M. Sun arXiv:1601.03741v3 [astro-ph.CO] 4 Feb 2016, “Probing dark energy via galaxy cluster outskirts”
2. http://chandra.harvard.edu/photo/2016/clusters/

## Dark Sector Experiments

A dark energy experiment was recently searching for a so-called scalar “chameleon field”. Chameleon particles could be an explanation for dark energy. They would have to make the field strength vanishingly small when they are in regions of significant matter density, coupling to matter more weakly than does gravity. But in low-density regions, say between the galaxies, the chameleon particle would exert a long range force.

Chameleons can decay to photons, so that provides a way to detect them, if they actually exist.

Chameleon particles were originally suggested by Justin Khoury of the University of Pennsylvania and another physicist around 2003. Now Khoury and Holger Muller and collaborators at UC Berkeley have performed an experiment which pushed millions of cesium atoms toward an aluminum sphere in a vacuum chamber. By changing the orientation in which the experiment is performed, the researchers can correct for the effects of gravity and compare the putative chameleon field strength to gravity.

If there were a chameleon field, then the cesium atoms should accelerate at different rates depending on the orientation, but no difference was found. The level of precision of this experiment is such that only chameleons that interact very strongly with matter have been ruled out. The team is looking to increase the precision of the experiment by additional orders of magnitude.

For now the simplest explanation for dark energy is the cosmological constant (or energy of the vacuum) as Einstein proposed almost 100 years ago.

The Large Underground Xenon experiment to detect dark matter (CC BY 3.0)

“Dark radiation” has been hypothesized for some time by some physicists. In this scenario there would be a “dark electromagnetic” force and dark matter particles could annihilate into dark photons or other dark sector particles when two dark matter particles collide with one another. This would happen infrequently, since dark matter is much more diffusely distributed than ordinary matter.

Ordinary matter clumps since it undergoes frictional and ordinary radiation processes, emitting photons. This allows it to cool it off and to become more dense under mutual gravitational forces. Dark matter rarely decays or interacts, and does not interact electromagnetically, thus no friction or ordinary radiation occurs. Essentially dark matter helps ordinary matter clump together initially since it dominates on the large scales, but on small scales ordinary matter will be dominant in certain regions. Thus the density of dark matter in the solar system is very low.

Earthbound dark matter detectors have focused on direct interaction of dark matter with atomic nuclei for the signal. John Cherry and co-authors have suggested that dark matter may not interact directly, but rather it first annihilates to light particles, which then scatter on the atomic nuclei used as targets in the direct detection experiments.

So in this scenario dark matter particles annihilate when they encounter each other, producing dark radiation, and then the dark radiation can be detected by currently existing direct detection experiments. If this is the main channel for detection, then much lower mass dark matter particles can be observed, down to of order 10 MeV (million electron-Volts), whereas current direct detection is focused on masses of several GeV (billion electron-Volts) to 100 GeV or more. (The proton rest mass is about 1 GeV)

A Nobel Prize awaits, most likely, the first unambiguous direct detection of either dark matter, or dark energy, if it is even possible.

References

https://en.wikipedia.org/wiki/Chameleon_particle – Chameleon particle

http://scitechdaily.com/physicists-work-on-new-approach-to-detect-dark-matter/ – article on detecting dark matter generated dark radiation

http://journals.aps.org/prl/abstract/10.1103/PhysRevLett.114.231303 – Cherry et al. paper in Physical Review Letters

## Planck 2015 Constraints on Dark Energy and Inflation

The European Space Agency’s Planck satellite gathered data for over 4 years, and a series of 28 papers releasing the results and evaluating constraints on cosmological models have been recently released. In general, the Planck mission’s complete results confirm the canonical cosmological model, known as Lambda Cold Dark Matter, or ΛCDM. In approximate percentage terms the Planck 2015 results indicate 69% dark energy, 26% dark matter, and 5% ordinary matter as the mass-energy components of the universe (see this earlier blog:

Dark Energy

We know that dark energy is the dominant force in the universe, comprising 69% of the total energy content. And it exerts a negative pressure causing the expansion to continuously speed up. The universe is not only expanding, but the expansion is even accelerating! What dark energy is we do not know, but the simplest explanation is that it is the energy of empty space, of the vacuum. Significant departures from this simple model are not supported by observations.

The dark energy equation of state is the relation between the pressure exerted by dark energy and its energy density. Planck satellite measurements are able to constrain the dark energy equation of state significantly. Consistent with earlier measurements of this parameter, which is usually denoted as w, the Planck Consortium has determined that w = -1 to within 4 or 5 percent (95% confidence).

According to the Planck Consortium, “By combining the Planck TT+lowP+lensing data with other astrophysical data, including the JLA supernovae, the equation of state for dark energy is constrained to w = −1.006 ± 0.045 and is therefore compatible with a cosmological constant, assumed in the base ΛCDM cosmology.”

A value of -1 for w corresponds to a simple Cosmological constant model with a single parameter Λ  that is the present-day energy density of empty space, the vacuum. The Λ value measured to be 0.69 is normalized to the critical mass-energy density. Since the vacuum is permeated by various fields, its energy density is non-zero. (The critical mass-energy density is that which results in a topologically flat space-time for the universe; it is the equivalent of 5.2 proton masses per cubic meter.)

Such a model has a negative pressure, which leads to the accelerated expansion that has been observed for the universe; this acceleration was first discovered in 1998 by two teams using certain supernova as standard candle distance indicators, and measuring their luminosity as a function of redshift distance.

Modified gravity

The phrase modified gravity refers to models that depart from general relativity. To date, general relativity has passed every test thrown at it, on scales from the Earth to the universe as a whole. The Planck Consortium has also explored a number of modified gravity models with extensions to general relativity. They are able to tighten the restrictions on such models, and find that overall there is no need for modifications to general relativity to explain the data from the Planck satellite.

Primordial density fluctuations

The Planck data are consistent with a model of primordial density fluctuations that is close to, but not precisely, scale invariant. These are the fluctuations which gave rise to overdensities in dark matter and ordinary matter that eventually collapsed to form galaxies and the observed large scale structure of the universe.

The concept is that the spectrum of density fluctuations is a simple power law of the form

P(k) ∝ k**(ns−1),

where k is the wave number (the inverse of the wavelength scale). The Planck observations are well fit by such a power law assumption. The measured spectral index of the perturbations has a slight tilt away from 1, with the existence of the tilt being valid to more than 5 standard deviations of accuracy.

ns = 0.9677 ± 0.0060

The existence and amount of this tilt in the spectral index has implications for inflationary models.

Inflation

The Planck Consortium authors have evaluated a wide range of potential inflationary models against the data products, including the following categories:

• Power law
• Hilltop
• Natural
• D-brane
• Exponential
• Spontaneously broken supersymmetry
• Alpha attractors
• Non-minimally coupled

Figure 12 from Planck 2015 results XX Constraints on Inflation. The Planck 2015 data constraints are shown with the red and blue contours. Steeper models with  V ~ φ³ or V ~ φ² appear ruled out, whereas R² inflation looks quite attractive.

Their results appear to rule out some of these, although many models remain consistent with the data. Power law models with indices greater or equal to 2 appear to be ruled out. Simple slow roll models such as R² inflation, which is actually the first inflationary model proposed 35 years ago, appears more favored than others. Brane inflation and exponential inflation are also good fits to the data. Again, many other models still remain statistically consistent with the data.

Simple models with a few parameters characterizing the inflation suffice:

“Firstly, under the assumption that the inflaton* potential is smooth over the observable range, we showed that the simplest parametric forms (involving only three free parameters including the amplitude V (φ∗ ), no deviation from slow roll, and nearly power-law primordial spectra) are sufficient to explain the data. No high-order derivatives or deviations from slow roll are required.”

* The inflaton is the name cosmologists give to the inflation field

“Among the models considered using this approach, the R2 inflationary model proposed by Starobinsky (1980) is the most preferred. Due to its high tensor- to-scalar ratio, the quadratic model is now strongly disfavoured with respect to R² inflation for Planck TT+lowP in combination with BAO data. By combining with the BKP likelihood, this trend is confirmed, and natural inflation is also disfavoured.”

Isocurvature and tensor components

They also evaluate whether the cosmological perturbations are purely adiabatic, or include an additional isocurvature component as well. They find that an isocurvature component would be small, less than 2% of the overall perturbation strength. A single scalar inflaton field with adiabatic perturbations is sufficient to explain the Planck data.

They find that the tensor-to-scalar ratio is less than 9%, which again rules out or constrains certain models of inflation.

Summary

The simplest LambdaCDM model continues to be quite robust, with the dark energy taking the form of a simple cosmological constant. It’s interesting that one of the oldest and simplest models for inflation, characterized by a power law relating the potential to the inflaton amplitude, and dating from 35 years ago, is favored by the latest Planck results. A value for the power law index of less than 2 is favored. All things being equal, Occam’s razor should lead us to prefer this sort of simple model for the universe’s early history. Models with slow-roll evolution throughout the inflationary epoch appear to be sufficient.

The universe started simply, but has become highly structured and complex through various evolutionary processes.

References

Planck Consortium 2015 papers are at http://www.cosmos.esa.int/web/planck/publications – This site links to the 28 papers for the 2015 results, as well as earlier publications. Especially relevant are these – XIII Cosmological parameters, XIV Dark energy and modified gravity, and XX Constraints on inflation.

## Dark Energy Survey First Light!

Last month the Dark Energy Survey project achieved first light from its remote location in Chile’s Atacama Desert. The term first light is used by astronomers to refer to the first observation by a new instrument.

And what an instrument this is! It is in fact the world’s most powerful digital camera. This Dark Energy Camera, or DECam, is a 570 Megapixel optical survey camera with a very wide field of view. The field of view is over 2 degrees, which is rather unusual in optical astronomy. And the camera requires special CCDs that are sensitive in the red and infrared parts of the spectrum. This is because distant galaxies have their light shifted toward the red and the infrared by the cosmological expansion. If the galaxy redshift is one,  the light travels for about 8 billion years and the wavelength of light that the DECam detects is doubled, relative to what it was when it was originally emitted.

Image: DECam, near center of image, is deployed at the focus of the 4-meter Victor M. Blanco optical telescope in Chile (Credit: Dark Energy Survey Collaboration)

The DECam has been deployed to further our understanding of dark energy through not just one experimental method, but in fact four different methods. That’s how you solve tough problems – by attacking them on multiple fronts.

It’s taken 8 years to get to this point, and there have been some delays, as normal for large projects. But now this new instrument is mounted at the focal plane of the existing 4-meter telescope of the National Science Foundation’s Cerro Tololo Inter-American observatory in Chile. It will begin its program of planned measurements of several hundred million galaxies starting in December after several weeks of testing and calibration. Each image from the camera-telescope combination can capture up to 100,000 galaxies out to distances of up to 8 billion light years. This is over halfway back to the origin of the universe almost 14 billion years ago.

In a previous blog entry I talked about the DES and the 4 methods in some detail. In brief they are based on observations of:

1. Type 1a supernova (the method used to first detect dark energy)
2. Very large scale spatial correlations of galaxies separated by 500 million light-years (this experiment is known as Baryon Acoustic Oscillations since the galaxy separations reflect the imprint of sound waves in the very early universe, prior to galaxy formation)
3. The number of clusters of galaxies as a function of redshift (age of the universe)
4. Gravitational lensing, i.e. distortion of background images by gravitational effects of foreground clusters in accordance with general relativity

Image: NGC 1365, a barred spiral galaxy located in the Fornax cluster located 60 million light years from Earth (Credit: Dark Energy Survey Collaboration)

What does the Dark Energy Survey team, which has over 120 members from over 20 countries, hope to learn about dark energy? We already have a good handle on its magnitude, at around 73% presently of the universe’s total mass-energy density.

The big issue is does it behave as a cosmological constant or as something more complex? In other words, how does the dark energy vary over time and is there possibly some spatial variation as well? And what is its equation of state, or relationship between its pressure and density?

With a cosmological constant explanation the relationship is Pressure = – Energy_density, a negative pressure, which is necessary in any model of the dark energy, in order for it to drive the accelerated expansion seen for the universe. Current observations from other experiments, especially those measuring the cosmic microwave background, support an equation of state parameter within around 5% of the value -1, as represented in the equation in the previous sentence. This is consistent with the interpretation as a pressure resulting from the vacuum. Dark energy appears also to have a constant or nearly constant density per unit volume of space. It is unlike ordinary matter and dark matter, that both drop in mass density (and thus energy density) as the volume of the universe grows. Thus dark energy becomes ever more dominant over dark matter and ordinary matter as the universe continues to expand.

We can’t wait to see the first publication of results from research into the nature of dark energy using the DECam.

References:

http://www.noao.edu/news/2012/pr1204.php – Press release from National Optical Astronomical Observatory on DECam first light

www.darkenergysurvey.org

http://www.ctio.noao.edu/noao/ – Cerro Tololo Inter-American Observatory page

http://lambda.gsfc.nasa.gov/product/map/dr4/pub_papers/sevenyear/basic_results/wmap_7yr_basic_results.pdf – WMAP 7 year results on cosmic microwave background

https://darkmatterdarkenergy.com/2011/03/08/dark-energy-survey/

## Future of Our Runaway Universe (the next Trillion Years)

Future for our Sun: Ultraviolet image of the planetary nebula NGC 7293 also known as the Helix Nebula. It is the nearest example of what happens to a star, like our own Sun, as it approaches the end of its life when it runs out of fuel, expels gas outward and evolves into a much hotter, smaller and denser white dwarf star. Image Credit: NASA/JPL-Caltech/SSC

In the future, the average density of matter in the universe (both ordinary matter and dark matter) will continue to drop in proportion to the increasing spatial volume as the universe expands ever more rapidly. The dark energy density, however, behaves differently. Dark energy is an irreducible property of even empty space, so as new space is created, the dark energy density remains the same; it is believed to not only take the same value in all portions of space at a given time, but to also have had the same value (per unit volume) for many billions of years.

Since around 5 billion years ago, when the universe was 9 billion years old, the dark energy has dominated over both types of matter (ordinary and dark) and this dominance is only increasing with the universe’s continued expansion. Today it is 73% of the total mass-energy density and it will approach close to 100% in the future. The assumption is made that the cosmological constant or dark energy term that we measure today remains constant into the future. However it cannot be ruled out that it is changing very slowly or might change suddenly at some future date.

In the cosmological constant case, the scale factor for the size of the universe grows exponentially with time. This is known as the de Sitter solution to the equations of general relativity, and it indicates that the expansion of the universe is accelerating into a runaway condition. There is a single parameter, a timescale. Cosmological measurements indicate that the value is such that the size of the universe for each spatial dimension will double and redouble every 11 billion years (the volume will thus grow by 8 times each 11 billion years).

When the universe is 25 billion years old (now it’s 14 billion years old), distant galaxies will be about twice as far away as today (and 4 times fainter). Well before that time we’ll need to evacuate the Earth as the Sun will go into its red giant phase some 5 billion years from now, followed by a white dwarf phase – as shown in the image of the Helix planetary nebula above. When the universe is around 124 billion years old, distant galaxies on average will be 1000 times farther away from us than now. And after 234 billion years they will be an incredible million times farther away than now!

Year                                    Relative Distance                        Relative Brightness

14 billion (Now)                        1                                                1

25 billion                                    2                                                1/4

124 billion                                  1000                                         one-millionth

234 billion                                  1,000,000                               one-trillionth

The distant galaxies that we detect with the Hubble telescope and large Earth-bound telescopes will become invisible since their apparent luminosity will drop as the square of the increasing distance. For example at the time of 124 billion years, they will be 1 million times fainter (1000 squared). At the time of 234 billion years they will be a trillion times fainter (one million squared). Actually it will be worse than this since their light will be redshifted (stretched out by the cosmological expansion) by the same relative distance factor, so light emitted in the visible will be detected in the millimeter radio region when the universe is 100+ billion years old. This is without considering the evolution in their stellar populations, but only their lower mass, fainter stars will survive, further aggravating the situation.

Galaxies themselves are not changing very much in their size or in internal density, rather it is the spacing between galaxies that is on average growing rapidly. Galaxy groups and clusters that are today gravitationally bound will remain bound. Our home, the Milky Way galaxy, and its large neighbor the Andromeda galaxy, will stay together since they are gravitationally bound, and they may very well merge in several billion years due to tidal effects. All of the 40 or so galaxies and dwarf galaxies in our gravitationally bound Local Group may coalesce after 1 trillion years have passed.

Our light cone horizon, which determines which galaxies are even theoretically visible to us, is shrinking in relative terms. Sufficiently distant galaxies are already receding faster than the speed of light from our vantage point and are entirely hidden from us; if the inflationary model is correct as seems to be the case, the universe is immensely larger than what we are able to detect. This is possible and indeed happening because there are no constraints in special relativity or general relativity on the expansion rate of space itself; only the objects within space are constrained to moving at less than the speed of light relative to their local frames of reference.

An intelligent society in the very distant future, possibly our descendants who have moved to a planet in orbit around another star, would observe only one galaxy, namely their own. This would be a larger galaxy formed from the Milky Way and other members of the Local Group. All other galaxies would no longer be visible, first they would become too distant and too faint, and then they would be entirely beyond our light horizon. These descendants or other observers would believe their galaxy to be the only one in the universe, unless they had access to (and a willingness to believe in) very ancient research publications.

We are fortunate to live in this epoch – despite dark matter, dark energy, and dark gravity, the universe is young, and we are immersed in light.

References:

http://spiff.rit.edu/classes/phys240/lectures/future/future.html

The Five Ages of the Universe, Fred Adams and Greg Laughlin, Simon and Schuster, 1999

The Runaway Universe, Donald Goldsmith, Perseus Books, 2000

Dark Matter, Dark Energy, Dark Gravity, Stephen Perrenod, 2011, https://darkmatterdarkenergy.wordpress.com/where-to-find/
